ARC / 76
Ø76mm
For lightweight structures
Cabins, decks, gazebos and lightweight timber or bamboo structures.
- Typical helix
- Ø240 mm
- Shaft wall options
- ≈ 3 / 5–5.5 mm
Built from the ground up.
STRONG
FOUNDATIONS.
LASTING
FUTURES.
International engineering. Made in Bali. Screw pile foundation systems built for the realities of Indonesia.
Build your foundationExplore our projectsARCSTONE / 3D
Screw piles go inOne connected foundation system
SCROLL TO ASSEMBLE
THE BUILDING STAYS LEVEL.
15+years of team experience
3core pile diameters
360°from design to installation
BALI → IDlocal production. national ambition.
THE ARCSTONE SYSTEM
More than a pile.
One complete system.
A continuous load path, from the building to the ground. Every component works together.
ARC / 89Drag to explore
ARCSTONE / 3D
Geometry is illustrative. Final connections are project-specific.
BUILT FOR REAL TERRAIN
The land has its shape.
Your future has no limits.
Less excavation. Flexible access. A level beginning.
OUR PRODUCTS
The right foundation.
For your next project.
ARC / 89MOST VERSATILE
Ø89mm
Everyday foundations
Villas, houses, restaurants and permanent modular buildings.
- Typical helix
- Ø270 mm
- Shaft wall options
- ≈ 3 / 5–5.5 mm
ARC / 114
Ø114mm
Greater demands
Pools, heavier buildings and projects requiring additional capacity.
- Typical helix
- Ø300 mm
- Shaft wall options
- ≈ 3 / 5–5.5 mm
Diameter alone does not define load capacity. The complete foundation is engineered for your project.
STEEL / PROTECTION / LONGEVITYTWO MATERIAL ROUTES
Made for the elements.
Factory-galvanized pipe
SPINDO galvanized steel pipe, approximately 3.0–3.2 mm wall. Fabricated helices, welds and exposed areas receive their specified protective coating.
Thick-wall steel + hot-dip zinc
Approximately 5–5.5 mm wall. Fabricated first, then hot-dip galvanized in Surabaya, with a target zinc thickness of approximately 90 µm, verified against the coating records.
Spider foundations
Driven steel pipes for suitable sandy ground, with a purpose-designed central connection.
Custom structural interfaces
Connections for bamboo, timber, steel and designed concrete floor systems. Rock sites can be assessed for a separate expanding-anchor solution.
YOUR FOUNDATION, VISUALIZED
Your dimensions.
Your terrain. Your foundation.
Start with the size of your project. See the system take shape in seconds.
01 — DEFINE YOUR PROJECT
No soil test needed to explore. Final design always requires engineering review.
PRELIMINARY CONCEPT8 × 6 m
ARCSTONE / 3D
Drag to rotate · Pinch to zoomPILE GRID5 × 4
PILES20
DIAMETERØ89 mm
SPACING2.00 × 2.00 m
Double C100Standard frame
Pile lengths are for visualization only. Bearing depth must be established from soil and load data. Transparent terrain reveals the buried piles.
PRELIMINARY FOUNDATION CONCEPT
This visualization is generated for preliminary planning purposes only. Final pile spacing, pile diameter, pile length, helix configuration, steel grillage and reinforcement must be confirmed by Arcstone engineers based on the architectural design, structural loads, site topography and soil conditions.
ON THE GROUND
Real terrain.
Real foundations.
From tropical hillsides to open fields. Built by our team, for the conditions on site.
A new home above the hillside
Elevated timber construction
A level start on uneven ground
Double-channel foundation grid
Room for more possibilities
Multiple foundation platforms
A smaller footprint on the landscape
Screw piles on sloping terrain
FROM OUR SITES
The system, before assembly.
Pile heads and fabricated steel components, delivered and ready for the installation sequence.
THE PEOPLE BEHIND THE PILES
International experience.
Local by design.
ARCSTONE brings more than 15 years of international team experience to Indonesian construction. Our factory in North Bali makes complete screw pile systems, adapted to local ground, tropical weather and challenging access.
From analysis and fabrication to installation and final alignment, one team takes responsibility for the connected system. Bali is our starting point. Indonesia is our horizon.
NORTH BALI / OUR WORKSHOPA PROVEN PRINCIPLE. CONTINUALLY EVOLVING.
Almost two centuries in the making.
An idea takes root
Alexander Mitchell develops screw-pile foundations for difficult ground and marine structures.
Historical researchEngineering evolves
From lighthouses and bridges to buildings, anchoring systems and slope applications across international markets.
Practical team experience
Experience in demanding climates, from freezing winters and seasonal temperature swings to hot, humid sites.
A local next chapter
Made in Bali. Engineered for Indonesian sites. Local fabrication with a nationwide vision.
FROM FACTORY TO SITE
A clear process.
A connected team.
Assess & design
Soil, loads, topography and access define the foundation concept.
Fabricate & protect
Produce the piles, heads, channels and braces. Inspect the steelwork and coating.
Deliver & install
Set out the grid, install the piles and verify the project acceptance criteria.
Level & connect
Align the heads, assemble the grillage and complete the final inspection.
INSTALLATION EQUIPMENT
The right tools for the ground.
- Electric screw pile driverRotational installation of helical piles.
- Petrol-powered drilling rigPre-drilling and subsequent pile installation.
- Impact hammerDriving steel pipes for spider foundations in suitable sandy soil.
TEST. VALIDATE. BUILD.
Confidence starts
with real data.
On-site vertical compression testing with equipment rated up to 50 tonnes. The test programme, reaction system and target load are engineered for each site. This is a testing capability, not a universal pile load rating.
Receive recorded load–settlement data, photos and engineering recommendations.
TECHNICAL LIBRARY
The details matter.
Explore the range, materials and system details. Project-specific material certificates and inspection records form part of the agreed documentation scope.
